| Model |
SUN-9K-G02P1-EU-AM2 |
SUN-10K-G02P1-EU-AM2 |
SUN-10.5K-G02P1-EU-AM2 |
| PV String Input Date |
|
| Max. PV Input Power(kW) |
11.7 |
13 |
13.7 |
| Max. PV Input Voltage(V) |
550 |
| Start-up Voltage(V) |
80 |
| MPPT voltage range(V) |
70-500 |
| Rated PV Input voltage(V) |
360 |
| Max. Input Short Circuit Current (A) |
39+39 |
| Max. Operating PV Input Current(A) |
26+26 |
| No. of MPP Trackers/No. of Strings per MPP Tracker |
2/2+2 |
| AC Input/Output Side |
|
| Rated AC Output Active Power(kW) |
9 |
10 |
11 |
| Max. AC Output Apparent Power(kVA) |
9.9 |
11 |
11.55 |
| Rated AC output current (A) |
40.9/39.2 |
45.5/43.5 |
47.8/45.7 |
| Max. AC Output Current(A) |
45/43.1 |
50/47.9 |
52.5/50.3 |
| Rated output voltage/range (V) |
220/230 0.85Un-1.1Un |
| Grid Connection Form |
L/N/PE |
| Rated Output Grid Frequency/range(Hz) |
50/45-55, 60/55-65 |
| Power Factor Adjustment Range |
0.8 leading to 0.8lagging |
| Total Current Harmonic Distortion THDi |
<3% |
| DC Injection Current |
<0.5%ln |
| Efficiency |
|
| Max. Efficiency |
97.7% |
| Euro Efficiency |
97.2% |
| MPPT Efficiency |
＞99% |
| Equipment Protection |
|
| DC Polarity Reverse Connection Protection |
yes |
| AC Output Overcurrent Protection |
yes |
| AC Output Overvoltage Protection |
yes |
| AC Output Short Circuit Protection |
yes |
| Thermal Protection |
yes |
| DC Terminal Insulation Impedance Monitoring |
yes |
| DC Component Monitoring |
yes |
| Ground Fault Current Monitoring |
yes |
| Power Network Monitoring |
yes |
| Island Protection Monitoring |
yes |
| Earth Fault Detection |
yes |
| DC Input Switch |
yes |
| Overvoltage Load Drop Protection |
yes |
| Residual Current (RCD) Detection |
yes |
| Surge Protection Level |
TYPE II(DC),TYPE II(AC) |
| Interface |
|
| Communication Interface |
RS485/RS232 /WiFi/LAN |
| General Data |
|
| Operating Temperature Range (°C) |
-25 to +60℃, >45℃ Derating |
| Permissible Ambient Humidity |
0~100% |
| Permissible Altitude (m) |
3000m |
| Noise (dB) |
≤ 35 |
| Ingress Protection(IP) Rating |
IP 65 |
| Inverter Topology |
Non-Isolated |
| Over Voltage Category |
OVC II(DC),OVC III(AC) |
| Cabinet Size (WxHxD mm) |
330*410*213.5（Excluding connectors and brackets） |
| Weight [kg] |
14.8 |
| Warranty [year] |
5 years |
| Type Of Cooling |
natural cooling |
| Grid Regulation |
IEC 61727,IEC 62116,EN 50549,NRS 097,RD 140,UNE 217002,G99 |
| Safety EMC/Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
