Model
|
SUN-M60G3-EU-Q0
|
SUN-M80G3-EU-Q0
|
SUN-M100G3-EU-Q0
|
|
Input data (DC)
|
|||
|
Recommended Input Power (STC)
|
210-420W (2 Pieces)
|
210-600W (2 Pieces)
|
210-700W (2 Pieces)
|
|
Maximum Input DC Voltage (V)
|
60
|
||
|
MPPT Voltage Range (V)
|
25-55
|
||
|
Full Load DC Voltage Range (V)
|
30-55
|
33-55
|
40-55
|
|
Max. DC Short Circuit Current (A)
|
2×19.5
|
||
|
Max. Input Current (A)
|
2×13
|
||
|
No.of MPP Trackers
|
2
|
||
|
No.of Strings per MPP Tracker
|
1
|
||
|
Output Data (AC)
|
|||
|
Max. Output Apparent Power (VA)
|
600
|
800
|
1000
|
|
Rated Output Power (W)
|
600
|
800
|
1000
|
|
Rated Output Current (A)
|
2.8/2.7
|
3.7/3.5
|
4.6/4.4
|
|
Max.AC Output Current (A)
|
2.8/2.7
|
3.7/3.5
|
4.6/4.4
|
|
Grid Connection Form
Rated output voltage/range (V)
|
L+N+PE 220V/184V-242V 230V/ 195.5V-253V
|
||
|
Rated Grid Frequency/range (Hz)
|
50Hz/45Hz-55Hz 60Hz/55Hz-65Hz
|
||
|
Power Factor
|
>0.99
|
||
|
Total Harmonics Current Distortion (THDi)
|
<3%
|
||
|
Maximum Units per Branch
|
8 | 6 | 5 |
|
Efficiency
|
|||
|
Max Effificiency
|
96.5%
|
||
|
Static MPPT efficiency
|
99%
|
||
|
Night Time Power Consumption
|
50mW
|
||
|
Mechanical Data
|
|||
|
Ambient Temperature Range
|
-40-65℃, >45℃ derating
|
||
|
Cabinet Size (WxHxD mm)
|
190×212×40 (Excluding Connectors and Brackets)
|
||
|
Weight (kg)
|
2.8
|
||
|
cooling
|
Free Cooling
|
||
|
Enclosure Environmental Rating
|
IP67
|
||
|
Features
|
|||
|
Communication
|
WIFI
|
||
|
Grid Connection Standard
|
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE-Richtlinie R25, G98, VDE-AR-N 4105
|
||
|
Safety EMC / Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
||
|
Warranty
|
15 years
|
||
|
Network and System Protection Device
|
SUN-MI-RELAY-01
|
||
|
AC Intput Data (Inverter)
|
|||
|
Nominal Voltage
|
220V/230V
|
||
|
Nominal Frequency
|
50Hz
|
||
|
Max AC Current
|
12A
|
||
|
Nominal AC Current
|
12A
|
||
|
Matching Inverter
|
MicroInverter
|
||
|
AC Output Data(Grid)
|
|
||
|
Nominal Voltage
|
220V/230V
|
||
|
Nominal Frequency
|
50Hz
|
||
|
Max AC Current
|
12A
|
||
|
Nominal AC Current
|
12A
|
||
|
General Data
|
|
||
|
Ambient Temperature Range
|
-40-65℃
|
||
|
Humidity
|
0%-100% RH
|
||
|
Cabinet Size (WxHxD mm)
|
111×95×37.7 (Excluding Connectors and Brackets) |
||
|
Weight (kg)
|
0.34 |
||
|
Enclosure Environmental Rating
|
IP67 |
||
|
Communication
|
Wireless/WIFI |
||
|
Safety EMC / Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2, VDE-AR-N 4105
|
||
|
Warranty
|
15 Years
|
||
