Model
|
SUN-70K-G03
|
SUN-75K-G03
|
SUN-80K-G03
|
SUN-90K-G03
|
SUN-100K-G03
|
SUN-110K-G03
|
|
PV String Input Date
|
|
|
Max. PV Input Power(kW)
|
91
|
97.5
|
104
|
135
|
150
|
150
|
|
Max. PV Input Voltage(V)
|
1000
|
|
Start-up Voltage(V)
|
250
|
|
MPPT voltage range(V)
|
200-850
|
|
Rated PV Input voltage(V)
|
600
|
|
Max. Input Short Circuit Current (A)
|
60+60+60+60
|
60+60+60+60+60+60
|
|
Max. Operating PV Input Current(A)
|
40+40+40+40
|
40+40+40+40+40+40
|
|
No. of MPP Trackers/No. of Strings per MPP Tracker
|
4/4+4+4+4
|
6/4+4+4+4+4+4
|
|
AC Input/Output Side
|
|
|
Rated AC Output Active Power(kW)
|
70
|
75
|
80
|
90
|
100
|
110
|
|
Max. AC Output Apparent Power(kVA)
|
77
|
82.5
|
88
|
99
|
110
|
121
|
|
Rated AC output current (A)
|
106.1/101.5
|
113.6/108.7
|
121.2/115.9
|
136.4/130.4
|
151.5/144.9
|
166.7/159.4
|
|
Max. AC Output Current(A)
|
116.7/111.6
|
125/119.6
|
133.3/127.5
|
150/143.5
|
166.7/159.4
|
183.3/175.4
|
|
Rated output voltage/range (V)
|
220/380V, 230/400V 0.85Un-1.1Un
|
|
Grid Connection Form
|
3L+N+PE
|
|
Rated Output Grid Frequency/range(Hz)
|
50Hz/45Hz-55Hz 60Hz/55Hz-65Hz
|
|
Power Factor Adjustment Range
|
0.8 leading to 0.8lagging
|
|
Total Current Harmonic Distortion THDi
|
<3%
|
|
DC Injection Current
|
<0.5%ln
|
|
Efficiency
|
|
|
Max. Efficiency
|
98.7%
|
98.8%
|
|
Euro Efficiency
|
98.1%
|
98.2%
|
|
MPPT Efficiency
|
＞99%
|
|
Equipment Protection
|
|
|
DC Polarity Reverse Connection Protection
|
yes
|
|
AC Output Overcurrent Protection
|
yes
|
|
AC Output Overvoltage Protection
|
yes
|
|
AC Output Short Circuit Protection
|
yes
|
|
Thermal Protection
|
yes
|
|
DC Terminal Insulation Impedance Monitoring
|
yes
|
|
DC Component Monitoring
|
yes
|
|
Ground Fault Current Monitoring
|
yes
|
|
Power Network Monitoring
|
yes
|
|
Island Protection Monitoring
|
yes
|
|
Earth Fault Detection
|
yes
|
|
DC Input Switch
|
yes
|
|
Overvoltage Load Drop Protection
|
yes
|
|
Residual Current (RCD) Detection
|
yes
|
|
Surge Protection Level
|
TYPE II(DC),TYPE II(AC)
|
|
Interface
|
|
|
Communication Interface
|
RS485/RS232 /WiFi/LAN
|
|
General Data
|
|
|
Operating Temperature Range (°C)
|
-25 to +65℃, >45
℃ Derating
|
|
Permissible Ambient Humidity
|
0~100%
|
|
Permissible Altitude (m)
|
4000m
|
|
Noise (dB)
|
≤ 55
|
|
Ingress Protection(IP) Rating
|
IP 65
|
|
Inverter Topology
|
Non-Isolated
|
|
Over Voltage Category
|
OVC II(DC),OVC III(AC)
|
|
Cabinet Size (WxHxD mm)
|
826mm*516mm*312.7mm（Excluding connectors and brackets）
|
|
Weight [kg]
|
81
|
|
Warranty [year]
|
5 years
|
|
Type Of Cooling
|
Intelligent air cooling
|
|
Grid Regulation
|
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE-Richtlinie R25, G99, VDE-AR-N 4105
|
|
Safety EMC/Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
