| Model | SUN-4K-G06 | SUN-5K-G06 | SUN-6K-G06 | SUN-7K-G06 | SUN-8K-G06 | SUN-10K-G05 | SUN-12K-G06 |
| PV String Input Date | |||||||
| Max. PV Input Power(kW) | 5.2 | 6.5 | 7.8 | 9.1 | 10.4 | 13 | 15.6 |
| Max. PV Input Voltage(V) | 1100 | ||||||
| Start-up Voltage(V) | 140 | ||||||
| MPPT voltage range(V) | 120-1000 | ||||||
| Rated PV Input voltage(V) | 600 | ||||||
| Max. Operating PV Input Current (A) | 13+13 | ||||||
| Max. Input Short Circuit Current (A) | 19.5+19.5 | ||||||
| No. of MPP Trackers/No. of Strings per MPP Tracker | 2/1+1 | ||||||
| AC Input/Output Side | |||||||
| Rated AC Output Active Power(kW) | 4 | 5 | 6 | 7 | 8 | 10 | 12 |
| Max. AC Output Apparent Power(kVA) | 4.4 | 5.5 | 6.6 | 7.7 | 8.8 | 11 | 13.2 |
| Rated AC output current (A) | 6.1/5.8 | 7.6/7.3 | 9.1/8.7 | 10.7/10.2 | 12.2/11.6 | 15.2/14.5 | 18.2/17.4 |
| Max. AC Output Current(A) | 6.7/6.4 | 8.4/8 | 10/9.6 | 11.7/11.2 | 13.4/12.8 | 16.7/16 | 20/19.2 |
| Rated output voltage/range (V) | 220/380V, 230/400V 0.85Un-1.1Un | ||||||
| Grid Connection Form | 3L/N/PE | ||||||
| Rated Output Grid Frequency/range(Hz) | 50/45-55, 60/55-65 | ||||||
| Power Factor Adjustment Range | 0.8 leading to 0.8lagging | ||||||
| Total Current Harmonic Distortion THDi | <3% | ||||||
| DC Injection Current | <0.5%ln | ||||||
| Efficiency | |||||||
| Max. Efficiency | 98.3% | ||||||
| Euro Efficiency | 97.8% | ||||||
| MPPT Efficiency | ＞99% | ||||||
| Equipment Protection | |||||||
| DC Polarity Reverse Connection Protection | yes | ||||||
| AC Output Overcurrent Protection | yes | ||||||
| AC Output Overvoltage Protection | yes | ||||||
| AC Output Short Circuit Protection | yes | ||||||
| Thermal Protection | yes | ||||||
| DC Terminal Insulation Impedance Monitoring | yes | ||||||
| DC Component Monitoring | yes | ||||||
| Ground Fault Current Monitoring | yes | ||||||
| Power Network Monitoring | yes | ||||||
| Island Protection Monitoring | yes | ||||||
| Earth Fault Detection | yes | ||||||
| DC Input Switch | yes | ||||||
| Overvoltage Load Drop Protection | yes | ||||||
| Residual Current (RCD) Detection | yes | ||||||
| Surge Protection Level | TYPE II(DC),TYPE II(AC) | ||||||
| Interface | |||||||
| Communication Interface | RS485/RS232 /WiFi/LAN | ||||||
| General Data | |||||||
| Operating Temperature Range (°C) | -25 to +60℃, >45℃ Derating | ||||||
| Permissible Ambient Humidity | 0~100% | ||||||
| Permissible Altitude (m) | 4000m | ||||||
| Noise (dB) | ＜45 | ||||||
| Ingress Protection(IP) Rating | IP 65 | ||||||
| Inverter Topology | Non-Isolated | ||||||
| Over Voltage Category | OVC II(DC),OVC III(AC) | ||||||
| Cabinet Size (WxHxD mm) | 283*463*178（Excluding connectors and brackets） | ||||||
| Weight [kg] | 11 | ||||||
| Warranty [year] | 5 years | ||||||
| Type Of Cooling | Natural Cooling | ||||||
| Grid Regulation |
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE-Richtlinie R25, G99, VDE-AR-N 4105
|
||||||
| Safety EMC/Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | ||||||
