Model
|
SUN-7.6K-SG02LP1-EU-AM2
|
SUN-8K-SG02LP1-EU-AM2
|
SUN-10K-SG02LP1-EU-AM3
|
SUN-12K-SG02LP1-EU-AM3
|
|
Battery Input Data
|
|
|
Battery Type
|
Lead-acid or Lithium-ion
|
|
Battery Voltage Range(V)
|
40-60
|
|
Max.Charging Current(A)
|
190
|
190
|
220
|
250
|
|
Max.Discharging Current(A)
|
190
|
190
|
220
|
250
|
|
Charging Strategy for Li-ion Battery
|
Self-adaption to BMS
|
|
Number of battery input
|
1
|
|
PV String Input Data
|
|
|
Max DC Input Power（W）
|
9880
|
10400
|
13000
|
15600
|
|
Max DC Input Voltage（V）
|
500
|
|
Start-up Voltage（V）
|
125
|
|
MPPT Voltage Range（V）
|
150-425
|
|
Rated DC Input Voltage(V)
|
370
|
|
Max. Operating PV Input Current (A)
|
26+26
|
26+26+26
|
|
Max. Input Short-Circuit Current (A)
|
44+44
|
44+44+44
|
|
No.of MPP Trackers/No.of String Per MPP Tracker
|
2/2+2
|
3/2+2+2
|
|
AC Input/Output Data
|
|
|
Rated AC Input/Output Active Power（W）
|
7600
|
8000
|
10000
|
12000
|
|
Max AC Input/Output Apparent Power （VA）
|
8360
|
8800
|
11000
|
13200
|
|
Peak Power (off-grid)（W）
|
2 times of rated power,10s
|
|
Rated AC Input/Output Current（A）
|
34.6/33.1
|
36.4/34.8
|
45.5/43.5
|
54.6/52.2
|
|
Max AC Input/Output Current（A）
|
38/36.4
|
40/38.3
|
50/47.9
|
60/57.4
|
|
Max Continuous AC Passthrough (grid to load)（A）
|
50
|
60
|
|
Power Factor Adjustment Range
|
0.8 leading to 0.8 lagging
|
|
Rated Input/Output Voltage/Range (V)
|
220/230 0.85Un-1.1Un
|
|
Rated Input/Output Grid Frequency/Range(Hz)
|
50/45-55, 60/55-65
|
|
Grid Connection Form
|
L+N+PE
|
|
Total Current Harmonic Distortion THDi
|
<3% (of nominal power)
|
|
DC Injection Current
|
<0.5%ln
|
|
Efficiency
|
|
|
Max Efficiency
|
97.6%
|
|
Euro Efficiency
|
96.5%
|
|
MPPT Efficiency
|
＞99%
|
|
Equipment Protection
|
|
|
DC Polarity Reverse Connection Protection
|
yes
|
|
AC Output Overcurrent Protection
|
yes
|
|
AC Output Overvoltage Protection
|
yes
|
|
AC Output Short Circuit Protection
|
yes
|
|
Thermal Protection
|
yes
|
|
DC Terminal Insulation Impedance Monitoring
|
yes
|
|
DC Component Monitoring
|
yes
|
|
Ground Fault Current Monitoring
|
yes
|
|
Power Network Monitoring
|
yes
|
|
Island Protection Monitoring
|
yes
|
|
Earth Fault Detection
|
yes
|
|
DC Input Switch
|
yes
|
|
Overvoltage Load Drop Protection
|
yes
|
|
Residual Current (RCD) Detection
|
yes
|
|
Surge Protection Level
|
TYPE II(DC),TYPE II(AC)
|
|
Interface
|
|
|
Communication Interface
|
WIFI, RS485, CAN
|
|
General Data
|
|
|
Operating Temperature Range
|
-40 to +60℃
, >45℃
Derating
|
|
Permissible Ambient Humidity
|
0~100%
|
|
Permissible Altitude
|
2000m
|
|
Noise
|
＜45
|
|
Ingress Protection(IP) Rating
|
IP 65
|
|
Inverter Topology
|
Non-Isolated
|
|
Over Voltage Category
|
OVC II(DC),OVC IV(AC)
|
|
Cabinet size（W*H*D）[mm]
|
420×670×233（Excluding connectors and brackets）
|
|
Weight[kg]
|
35.6
|
|
Warranty
|
5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
|
|
Type Of Cooling
|
Intelligent air cooling
|
|
Grid Regulation
|
EVDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0 21, EN50549-1,
G98, G99, C10-11, UNE217002, NBR16149/NBR16150
|
|
Safety EMC/Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
