Model
|
SUN-5K-SG04LP3-AU
|
SUN-6K-SG04LP3-AU
|
SUN-8K-SG04LP3-AU
|
SUN-10K-SG04LP3-AU
|
SUN-12K-SG04LP3-AU
|
|
Battery Input Data
|
|
|
Battery Type
|
Lead-acid or Lithium-ion
|
|
Battery Voltage Range(V)
|
40-60
|
|
Max.Charging Current(A)
|
120
|
150
|
190
|
210
|
240
|
|
Max.Discharging Current(A)
|
120
|
150
|
190
|
210
|
240
|
|
External Temperature Sensor
|
Yes
|
|
Charging Curve
|
3 Stages / Equalization
|
Charging Strategy for Li-ion Battery
|
Self-adaption to BMS
|
|
PV String Input Data
|
|
|
Max. PV Input Power (W)
|
7500
|
9000
|
12000
|
15000
|
18000
|
|
Rated PV Input Voltage（V）
|
550 (160-800)
|
|
Start-up Voltage（V）
|
160
|
|
MPPT Voltage Range（V）
|
200-650
|
|
Full Load PV Voltage Range (V)
|
350-650
|
|
PV Input Current (A)
|
13+13
|
26+13
|
|
Max. Input Short-Circuit Current (A)
|
19.5+19.5
|
39+19.5
|
|
No.of MPP Trackers/No.of String Per MPP Tracker
|
2/1+1
|
2/2+1
|
|
AC Output Data
|
|
|
Rated AC Output and UPS Power (W)
|
5000
|
6000
|
8000
|
10000
|
12000
|
Rated Apparent Output Power (VA)
|
5000
|
6000
|
8000
|
10000
|
12000
|
|
Max AC Output Power（VA）
|
5000
|
6000
|
8000
|
10000
|
12000
|
|
Rated AC Output Current（A）
|
7.2
|
8.7
|
11.6
|
14.5
|
17.4
|
|
Max AC Output Current（A）
|
7.2
|
8.7
|
11.6
|
14.5
|
17.4
|
|
Max. Three-phase Unbalanced Output Current（A）
|
10.9
|
13
|
17.4
|
21.7
|
26.1
|
|
Max Continuous AC Passthrough (grid to load)（A）
|
45
|
|
Peak Power (off-grid)（W）
|
2 times of rated power, 10s
|
|
Power Factor Adjustment Range
|
0.8 leading to 0.8 lagging
|
|
Output Frequency and Voltage
|
50Hz; 3L/N/PE 230/400, 240/415Vac
|
Grid Connection Form
|
3L+N+PE
|
|
Total Current Harmonic Distortion THDi
|
<3% (of nominal power)
|
|
DC Injection Current
|
<0.5%ln
|
|
Efficiency
|
|
|
Max Efficiency
|
97.6%
|
|
Euro Efficiency
|
97.0%
|
|
MPPT Efficiency
|
99.9%
|
|
Protection
|
|
|
Integrated
|
Anti-islanding Protection, PV String Input Reverse Polarity Protection,
Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection,
Output Shorted Protection, Surge protection
|
Over Voltage Category
|
DC Type II/AC Type III
|
|
General Data
|
|
|
Operating Temperature Range
|
-40 to +60℃, >45
℃ Derating
|
|
Cooling
|
Smart cooling
|
|
Noise
|
≤ 55 dB(A)
|
|
Ingress Protection(IP) Rating
|
IP 65
|
|
Communication with BMS
|
RS485; CAN
|
|
Installation Style
|
Wall-mounted
|
|
Cabinet size（W*H*D）[mm]
|
422×658×254（Excluding connectors and brackets）
|
|
Weight[kg]
|
38
|
|
Warranty
|
10 Years
|
|
Grid Regulation
|
AS/NZS 4777.2
|
|
Safety EMC/Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
