| Model | SUN-120K-G01P3 | SUN-125K-G01P3 | SUN-130K-G01P3 | SUN-135K-G01P3 | SUN-136K-G01P3 |
| PV String Input Date | |||||
| Max. PV Input Power(kW) | 180 | 187.5 | 195 | 202.5 | 204 |
| Max. PV Input Voltage(V) | 1100 | ||||
| Start-up Voltage(V) | 250 | ||||
| MPPT voltage range(V) | 200-1000 | ||||
| Rated PV Input voltage(V) | 600 | ||||
| Max. Input Short Circuit Current (A) | 60+60+60+60+60+60+60+60 | ||||
| Max. Operating PV Input Current(A) | 40+40+40+40+40+40+40+40 | ||||
| No. of MPP Trackers/No. of Strings per MPP Tracker | 8/4+4+4+4+4+4+4+4 | ||||
| AC Input/Output Side | |||||
| Rated AC Output Active Power(kW) | 120 | 125 | 130 | 135 | 136 |
| Max. AC Output Apparent Power(kVA) | 132 | 135 | 135 | 135 | 136 |
| Rated AC output current (A) | 181.9/174.0 | 189.4/181.2 | 197/188.5 | 204.6/195.7 | 206.1/197.2 |
| Max. AC Output Current(A) | 200/191.4 | 204.6/195.7 | 204.6/195.7 | 204.6/195.7 | 206.1/197.2 |
| Rated output voltage/range (V) |
220/380V,
230/400V 0.85Un-1.1Un
|
||||
| Grid Connection Form | 3L+N+PE | ||||
| Rated Output Grid Frequency/range(Hz) | 50Hz/45Hz-55Hz 60Hz/55Hz-65Hz | ||||
| Power Factor Adjustment Range | 0.8 leading to 0.8lagging | ||||
| Total Current Harmonic Distortion THDi | <3% | ||||
| DC Injection Current | <0.5%ln | ||||
| Efficiency | |||||
| Max. Efficiency | 98.8% | ||||
| Euro Efficiency | 98.2% | ||||
| MPPT Efficiency | ＞99% | ||||
| Equipment Protection | |||||
| DC Polarity Reverse Connection Protection | YES | ||||
| AC Output Overcurrent Protection | YES | ||||
| AC Output Overvoltage Protection | YES | ||||
| AC Output Short Circuit Protection | YES | ||||
| Thermal Protection | YES | ||||
| DC Terminal Insulation Impedance Monitoring | YES | ||||
| DC Component Monitoring | YES | ||||
| Ground Fault Current Monitoring | YES | ||||
| Power Network Monitoring | YES | ||||
| Island Protection Monitoring | YES | ||||
| Earth Fault Detection | YES | ||||
| DC Input Switch | YES | ||||
| Overvoltage Load Drop Protection | YES | ||||
| Residual Current (RCD) Detection | YES | ||||
| Surge Protection Level | TYPE II(DC),TYPE II(AC) | ||||
| Interface | |||||
| Communication Interface | RS485/RS232 /WiFi/LAN | ||||
| General Data | |||||
| Operating Temperature Range (°C) | ‘-25 to +60℃, >45 ℃ Derating | ||||
| Permissible Ambient Humidity | 0~100% | ||||
| Permissible Altitude (m) | 4000m | ||||
| Noise (dB) | ≤ 65 dB(A) | ||||
| Ingress Protection(IP) Rating | IP 65 | ||||
| Inverter Topology | Non-Isolated | ||||
| Over Voltage Category | OVC II(DC),OVC III(AC) | ||||
| Cabinet Size (WxHxD mm) | 1006mm*516mm*325.5mm（Excluding connectors and brackets） | ||||
| Weight [kg] | 103 | ||||
| Warranty [year] | 5 years | ||||
| Type Of Cooling | Intelligent air cooling | ||||
| Grid Regulation | IEC 61727,IEC 62116,CEI 0-21,CEI 0-16,EN 50549，NRS 097,RD 140,UNE 217002,OVE-Richtlinie R25,G99,VDE-AR-N 4105 | ||||
| Safety EMC/Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | ||||
