| Model | SUN-4K-G06P3-EU-AM2-P1 | SUN-5K-G06P3-EU-AM2-P1 | SUN-6K-G06P3-EU-AM2-P1 | SUN-7K-G06P3-EU-AM2-P1 | SUN-8K-G06P3-EU-AM2-P1 | SUN-10K-G06P3-EU-AM2-P1 | SUN-12K-G06P3-EU-AM2-P1 | SUN-15K-G06P3-EU-AM2-P1 |
| PV String Input Date | ||||||||
| Max. PV Input Power(kW) | 5.2 | 6.5 | 7.8 | 9.1 | 10.4 | 13 | 15.6 | 19.5 |
| Max. PV Input Voltage(V) | 1100 | |||||||
| Start-up Voltage(V) | 140 | |||||||
| MPPT voltage range(V) | 120-1000 | |||||||
| Rated PV Input voltage(V) | 600 | |||||||
| Max. Input Short Circuit Current (A) | 30+30 | 30+39 | ||||||
| Max. Operating PV Input Current(A) | 20+20 | 20+26 | ||||||
| No. of MPP Trackers/No. of Strings per MPP Tracker | 2/1+1 | 2/1+2 | ||||||
| AC Input/Output Side | ||||||||
| Rated AC Output Active Power(kW) | 4 | 5 | 6 | 7 | 8 | 10 | 12 | 15 |
| Max. AC Output Apparent Power(kVA) | 4.4 | 5.5 | 6.6 | 7.7 | 8.8 | 11 | 13.2 | 16.5 |
| Rated AC output current (A) | 6.1/5.8 | 7.6/7.3 | 9.1/8.7 | 10.7/10.2 | 12.2/11.6 | 15.2/14.5 | 18.2/17.4 | 22.8/21.8 |
| Max. AC Output Current(A) | 6.7/6.4 | 8.4/8 | 10/9.6 | 11.7/11.2 | 13.4/12.8 | 16.7/16 | 20/19.2 | 25/24 |
| Rated output voltage/range (V) | 220/380V, 230/400V 0.85Un-1.1Un | |||||||
| Grid Connection Form | 3L/N/PE | |||||||
| Rated Output Grid Frequency/range(Hz) | 50/45-55, 60/55-65 | |||||||
| Power Factor Adjustment Range | 0.8 leading to 0.8lagging | |||||||
| Total Current Harmonic Distortion THDi | <3% | |||||||
| DC Injection Current | <0.5%ln | |||||||
| Efficiency | ||||||||
| Max. Efficiency | 98.1% | 98.2% | 98.3% | 98.5% | ||||
| Euro Efficiency | 97.5% | 97.6% | 97.8% | 98.0% | ||||
| MPPT Efficiency | ＞99% | |||||||
| Equipment Protection | ||||||||
| DC Polarity Reverse Connection Protection | yes | |||||||
| AC Output Overcurrent Protection | yes | |||||||
| AC Output Overvoltage Protection | yes | |||||||
| AC Output Short Circuit Protection | yes | |||||||
| Thermal Protection | yes | |||||||
| DC Terminal Insulation Impedance Monitoring | yes | |||||||
| DC Component Monitoring | yes | |||||||
| Ground Fault Current Monitoring | yes | |||||||
| Power Network Monitoring | yes | |||||||
| Island Protection Monitoring | yes | |||||||
| Earth Fault Detection | yes | |||||||
| DC Input Switch | yes | |||||||
| Overvoltage Load Drop Protection | yes | |||||||
| Residual Current (RCD) Detection | yes | |||||||
| Surge Protection Level | TYPE II(DC),TYPE II(AC) | |||||||
| Interface | ||||||||
| Communication Interface | RS485/RS232 /WiFi/LAN | |||||||
| General Data | ||||||||
| Operating Temperature Range (°C) | -25 to +60℃, >45℃ Derating | |||||||
| Permissible Ambient Humidity | 0~100% | |||||||
| Permissible Altitude (m) | 4000m | |||||||
| Noise (dB) | ＜45 dB(A) | |||||||
| Ingress Protection(IP) Rating | IP 65 | |||||||
| Inverter Topology | Non-Isolated | |||||||
| Over Voltage Category | OVC II(DC),OVC III(AC) | |||||||
| Cabinet Size (WxHxD mm) | 283mm*463mm*178mm（Excluding connectors and brackets） | |||||||
| Weight [kg] | 11 | |||||||
| Warranty [year] | 5 years | |||||||
| Type Of Cooling | natural cooling | Intelligent air cooling | ||||||
| Grid Regulation | IEC 61727,IEC 62116,EN 50549 | |||||||
| Safety EMC/Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | |||||||
