Model
|
SUN-12K-SG01HP3-US-AM2
|
SUN-15K -SG01HP3-US-AM2
|
|
Battery Input Data
|
|
|
Battery Type
|
Lithium-ion
|
|
Battery Voltage Range(V)
|
160-500
|
|
Max.Charging Current(A)
|
50
|
|
Max.Discharging Current(A)
|
50
|
|
Charging Strategy for Li-ion Battery
|
Self-adaption to BMS
|
|
Number of battery input
|
1
|
|
PV String Input Data
|
|
|
Max DC Input Power（W）
|
12000
|
15000
|
|
Max DC Input Voltage（V）
|
550
|
|
Start-up Voltage（V）
|
180
|
|
MPPT Voltage Range（V）
|
150-500
|
|
Rated DC Input Voltage(V)
|
380
|
|
Max Input Short-Circuit Current（A）
|
39+39
|
|
Max Operating PV Input Current（A）
|
26+26
|
|
No.of MPP Trackers/No.of String Per MPP Tracker
|
2/2+2
|
|
AC Input/Output Data
|
|
|
Rated AC Input/Output Active Power（W）
|
12000
|
15000
|
|
Max AC Input/Output Apparent Power （VA）
|
12000
|
15000
|
|
Peak Power (off-grid)（W）
|
1.5 times of rated power,10s
|
|
Rated AC Input/Output Current（A）
|
50
|
62.5
|
|
Max AC Input/Output Current（A）
|
50
|
62.5
|
|
Max. Three-phase Unbalanced Output Current（A）
|
50
|
62.5
|
|
Max Continuous AC Passthrough (grid to load)（A）
|
150
|
|
Rated Input/Output Voltage/Range(V)
|
120/240,208 0.85Un-1.1Un
|
|
Grid Connection Form
|
2L+N+PE
|
|
Rated Input/Output Grid Frequency/Range
|
60Hz/55Hz-65Hz
|
|
Power Factor Adjustment Range
|
0.8 leading-0.8 lagging
|
|
Total Current Harmonic Distortion THDi
|
<3% (of nominal power)
|
|
DC Injection Current
|
<0.5%ln
|
|
Efficiency
|
|
|
Max Efficiency
|
97.60%
|
|
Euro Efficiency
|
96.50%
|
|
MPPT Efficiency
|
＞99%
|
|
Equipment Protection
|
|
|
DC Polarity Reverse Connection Protection
|
YES
|
|
AC Output Overcurrent Protection
|
YES
|
|
AC Output Overvoltage Protection
|
YES
|
|
AC Output Short Circuit Protection
|
YES
|
|
Thermal Protection
|
YES
|
|
DC Terminal Insulation Impedance Monitoring
|
YES
|
|
DC Component Monitoring
|
YES
|
|
Ground Fault Current Monitoring
|
YES
|
|
Power Network Monitoring
|
YES
|
|
Island Protection Monitoring
|
YES
|
|
Earth Fault Detection
|
YES
|
|
DC Input Switch
|
YES
|
|
Overvoltage Load Drop Protection
|
YES
|
|
Residual Current (RCD) Detection
|
YES
|
|
Surge Protection Level
|
TYPE II(DC),TYPE II(AC)
|
|
Interface
|
|
|
Communication Interface
|
WIFI,RS485，CAN
|
|
General Data
|
|
|
Operating Temperature Range
|
-40 to +60℃, >45℃ Derating
|
|
Permissible Ambient Humidity
|
0-100%
|
|
Permissible Altitude
|
2000m
|
|
Noise
|
≤ 55 dB(A)
|
|
Ingress Protection(IP) Rating
|
TYPE3R
|
|
Inverter Topology
|
Non-Isolated
|
|
Over Voltage Category
|
OVC II(DC),OVC III(AC)
|
|
Cabinet size（W*H*D）[mm]
|
408*678*247（Excluding connectors and brackets）
|
|
Weight[kg]
|
30
|
|
Warranty
|
5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
|
|
Type Of Cooling
|
Intelligent air cooling
|
|
Grid Regulation
|
IEEE 1547.1, SRD V2.0
|
|
Safety EMC/Standard
|
FCC, UL 1741
|
