Model
|
SUN-5K -SG01HP3-AU-AM2
|
SUN-6K -SG01HP3-AU-AM2
|
SUN-8K -SG01HP3-AU-AM2
|
SUN-10K -SG01HP3-AU-AM2
|
SUN-12K -SG01HP3-AU-AM2
|
SUN-15K -SG01HP3-AU-AM2
|
SUN-20K -SG01HP3-AU-AM2
|
SUN-25K -SG01HP3-AU-AM2
|
|
Battery Input Data
|
|
|
Battery Type
|
Lithium-ion
|
|
Battery Voltage Range(V)
|
160-700
|
|
Max.Charging Current(A)
|
30
|
30
|
37
|
50
|
|
Max.Discharging Current(A)
|
30
|
30
|
37
|
50
|
|
Charging Strategy for Li-ion Battery
|
Self-adaption to BMS
|
|
Number of battery input
|
1
|
|
PV String Input Data
|
|
|
Max PV Input Power（W）
|
7500
|
9000
|
12000
|
15000
|
18000
|
22500
|
30000
|
37500
|
|
Max PV Input Voltage（V）
|
1000
|
|
Start-up Voltage（V）
|
180
|
|
MPPT Range（V）
|
150-850
|
|
Full Load PV Voltage Range (V)
|
195-850
|
195-850
|
260-850
|
325-850
|
340-850
|
420-850
|
500-850
|
625-850
|
|
Rated PV Input Voltage (V)
|
600
|
700
|
|
Max. PV ISC (A)
|
30+30
|
39+30
|
39+39
|
|
PV Input Current (A)
|
20+20
|
26+20
|
26+26
|
|
No.of MPP Trackers/No.of String Per MPP Tracker
|
2/1+1
|
2/2+1
|
2/2+2
|
|
AC Input/Output Data
|
|
|
Rated AC Input/Output Active Power（W）
|
5000
|
6000
|
8000
|
10000
|
12000
|
15000
|
20000
|
25000
|
|
Rated Apparent Output Power (VA)
|
5000
|
6000
|
8000
|
10000
|
12000
|
15000
|
20000
|
25000
|
|
Max. AC Output Power (W)
|
5000
|
6000
|
8000
|
10000
|
12000
|
15000
|
20000
|
25000
|
|
Peak Power (off-grid)（W）
|
1.5 times of rated power,10s
|
|
AC Output Rated Current (A)
|
7.3
|
8.7
|
11.6
|
14.5
|
17.4
|
21.8
|
29
|
36.3
|
|
Max. AC Output Current（A）
|
7.3
|
8.7
|
11.6
|
14.5
|
17.4
|
21.8
|
29
|
36.3
|
|
Max. Three-phase Unbalanced Output Current
|
13
|
13
|
18
|
22
|
25
|
30
|
35
|
41.7
|
|
Max Continuous AC Passthrough （A）
|
40
|
80
|
|
Generator input/Smart load
/AC couple current (A)
|
7.3/40/7.3
|
8.7/40/8.7
|
11.6/40/11.6
|
14.5/40/14.5
|
17.4/80/17.4
|
21.8/80/21.8
|
29/80/29
|
36.3/80/36.3
|
|
Grid Connection Form
|
3L+N+PE
|
|
Output Frequency and Voltage
|
50/60Hz; 3L/N/PE 230/400, 240/415Vac
|
|
Power Factor
|
0.8 leading-0.8 lagging
|
|
Total Harmonics Current Distortion (THDi)
|
<3% (of nominal power)
|
|
DC current injection
|
<0.5%ln
|
|
Efficiency
|
|
|
Max Efficiency
|
97.6%
|
|
Euro Efficiency
|
97.0%
|
|
MPPT Efficiency
|
＞99.9%
|
|
Equipment Protection
|
|
|
Integrated
|
Anti-islanding Protection, PV String Input Reverse Polarity Protection,
Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection,
Output Shorted Protection, Surge Protection, Arc Fault Circuit Interruption (AFCI optional)
|
|
|
|
|
Over Voltage Category
|
DC Type II/AC Type III
|
|
Certifications and Standards
|
|
|
Grid Regulation
|
AS/NZS 4777.2
|
|
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
|
General Data
|
|
|
Operating Temperature Range(℃)
|
-40 to +60℃, >45℃ Derating
|
|
Communication with BMS
|
RS485; CAN
|
|
Noise
|
≤ 55 dB(A)
|
|
Protection Degree
|
IP 65
|
|
Installation Style
|
Wall-mounted
|
|
Inverter topology
|
Non-isolated
|
|
Size (mm)
|
408*638*237（Excluding connectors and brackets）
|
|
Weight[kg]
|
30.5
|
|
Cooling
|
Free Cooling
|
Smart cooling
|
|
Warranty
|
|
