Model
|
SUN-5K -SG01HP3-EU-AM2
|
SUN-6K -SG01HP3-EU-AM2
|
SUN-8K -SG01HP3-EU-AM2
|
SUN-10K -SG01HP3-EU-AM2
|
SUN-12K -SG01HP3-EU-AM2
|
SUN-15K -SG01HP3-EU-AM2
|
SUN-20K -SG01HP3-EU-AM2
|
SUN-25K -SG01HP3-EU-AM2
|
|
Battery Input Data
|
|
|
Battery Type
|
Lithium-ion
|
|
Battery Voltage Range(V)
|
160-700
|
|
Max.Charging Current(A)
|
30
|
30
|
37
|
50
|
|
Max.Discharging Current(A)
|
30
|
30
|
37
|
50
|
|
Charging Strategy for Li-ion Battery
|
Self-adaption to BMS
|
|
Number of battery input
|
1
|
|
PV String Input Data
|
|
|
Max DC Input Power（W）
|
6500
|
7800
|
10400
|
13000
|
15600
|
19500
|
26000
|
32500
|
|
Max DC Input Voltage（V）
|
1000
|
|
Start-up Voltage（V）
|
180
|
|
MPPT Voltage Range（V）
|
150-850
|
|
Rated DC Input Voltage(V)
|
600
|
700
|
|
Max Input Short-Circuit Current（A）
|
30+30
|
39+30
|
39+39
|
|
Max Operating PV Input Current（A）
|
20+20
|
26+20
|
26+26
|
|
No.of MPP Trackers/No.of String Per MPP Tracker
|
2/1+1
|
2/2+1
|
2/2+2
|
|
AC Input/Output Data
|
|
|
Rated AC Input/Output Active Power（W）
|
5000
|
6000
|
8000
|
10000
|
12000
|
15000
|
20000
|
25000
|
|
Max AC Input/Output Apparent Power （VA）
|
5500
|
6600
|
8800
|
11000
|
13200
|
16500
|
22000
|
27500
|
|
Peak Power (off-grid)（W）
|
1.5 times of rated power,10s
|
|
Rated AC Input/Output Current（A）
|
7.6/7.3
|
9.1/8.7
|
12.2/11.6
|
15.2/14.5
|
18.2/17.4
|
22.8/21.8
|
30.4/29
|
37.9/36.3
|
|
Max AC Input/Output Current（A）
|
8.4/8
|
10/9.6
|
13.4/12.8
|
16.7/16
|
20/19.2
|
25/24
|
33.4/31.9
|
41.7/39.9
|
|
Max. Three-phase Unbalanced Output Current（A）
|
13
|
13
|
18
|
22
|
25
|
30
|
35
|
41.7
|
|
Max Continuous AC Passthrough (grid to load)（A）
|
40
|
80
|
|
Rated Input/Output Voltage/Range(V)
|
220/380V，230/400V 0.85Un-1.1Un
|
|
Grid Connection Form
|
3L+N+PE
|
|
Rated Input/Output Grid Frequency/Range
|
50Hz/45Hz-55Hz 60Hz/55Hz-65Hz
|
|
Power Factor Adjustment Range
|
0.8 leading to 0.8 lagging
|
|
Total Current Harmonic Distortion THDi
|
<3% (of nominal power)
|
|
DC Injection Current
|
<0.5%ln
|
|
Efficiency
|
|
|
Max Efficiency
|
97.6%
|
|
Euro Efficiency
|
97.0%
|
|
MPPT Efficiency
|
＞99%
|
|
Equipment Protection
|
|
|
DC Polarity Reverse Connection Protection
|
YES
|
|
AC Output Overcurrent Protection
|
YES
|
|
AC Output Overvoltage Protection
|
YES
|
|
AC Output Short Circuit Protection
|
YES
|
|
Thermal Protection
|
YES
|
|
DC Terminal Insulation Impedance Monitoring
|
YES
|
|
DC Component Monitoring
|
YES
|
|
Ground Fault Current Monitoring
|
YES
|
|
Power Network Monitoring
|
YES
|
|
Island Protection Monitoring
|
YES
|
|
Earth Fault Detection
|
YES
|
|
DC Input Switch
|
YES
|
|
Overvoltage Load Drop Protection
|
YES
|
|
Residual Current (RCD) Detection
|
YES
|
|
Surge Protection Level
|
TYPE II(DC),TYPE II(AC)
|
|
Interface
|
|
|
Communication Interface
|
WIFI,RS485，CAN
|
|
General Data
|
|
|
Operating Temperature Range
|
-40 to +60℃, >45℃ Derating
|
|
Permissible Ambient Humidity
|
0-100%
|
|
Permissible Altitude
|
2000m
|
|
Noise
|
≤ 55 dB(A)
|
|
Ingress Protection(IP) Rating
|
IP 65
|
|
Inverter Topology
|
Non-Isolated
|
|
Over Voltage Category
|
OVC II(DC),OVC III(AC)
|
|
Cabinet size（W*H*D）[mm]
|
408*638*237（Excluding connectors and brackets）
|
|
Weight[kg]
|
30.5
|
|
Warranty
|
5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
|
|
Type Of Cooling
|
natural cooling
|
Intelligent air cooling
|
|
Grid Regulation
|
IEC 61727,IEC 62116,CEI 0-21,EN 50549，NRS 097,RD 140,UNE 217002,OVE-Richtlinie R25,G99,VDE-AR-N 4105
|
|
Safety EMC/Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
