Model
|
SUN-1K-G04P1-EU-AM1
|
SUN-1.5K-G04P1-EU-AM1
|
SUN-2K-G04P1-EU-AM1
|
SUN-2.2K-G04P1-EU-AM1
|
SUN-2.5K-G04P1-EU-AM1
|
SUN-2.7K-G04P1-EU-AM1
|
SUN-3K-G04P1-EU-AM1
|
SUN-3.3K-G04P1-EU-AM1
|
SUN-3.6K-G04P1-EU-AM1
|
SUN-4K-G04P1-EU-AM1
|
|
PV String Input Date
|
|
Max. PV Input Power(kW)
|
1.3
|
2
|
2.6
|
2.9
|
3.3
|
3.5
|
3.9
|
4.3
|
4.7
|
5.2
|
|
Max. PV Input Voltage(V)
|
550
|
|
Start-up Voltage(V)
|
80
|
|
MPPT voltage range(V)
|
70-500
|
|
Rated PV Input voltage(V)
|
360
|
420
|
|
Max. Input Short Circuit Current (A)
|
30
|
|
Max. Operating PV Input Current(A)
|
20
|
|
No. of MPP Trackers/No. of Strings per MPP Tracker
|
1/1
|
|
AC Input/Output Side
|
|
Rated AC Output Active Power (kW)
|
1
|
1.5
|
2
|
2.2
|
2.5
|
2.7
|
3
|
3.3
|
3.6
|
4
|
|
Max. AC Output Apparent Power (kVA)
|
1.1
|
1.65
|
2.2
|
2.42
|
2.75
|
2.97
|
3.3
|
3.63
|
3.96
|
4.4
|
|
Rated AC output current (A)
|
4.6/4.4
|
6.8/6.5
|
9.1/8.7
|
10.0/9.6
|
11.4/10.9
|
12.3/11.8
|
13.7/13.1
|
15.0/14.4
|
16.4/15.7
|
18.2/17.4
|
|
Max. AC Output Current(A)
|
5/4.8
|
7.5/7.2
|
10/9.6
|
11.0/10.6
|
12.5/12
|
13.5/13
|
15/14.4
|
16.5/15.8
|
18/17.3
|
20/19.2
|
|
Rated output voltage/range (V)
|
220/230 0.85Un-1.1Un
|
|
Grid Connection Form
|
L+N+PE
|
|
Rated Output Grid Frequency/Range(Hz)
|
50Hz/45Hz-55Hz 60Hz/55Hz-65Hz
|
|
Power Factor Adjustment Range
|
0.8 leading to 0.8lagging
|
|
Total Current Harmonic Distortion THDi
|
<3%
|
|
DC Injection Current
|
<0.5%ln
|
|
Efficiency
|
|
Max. Efficiency
|
97.3%
|
97.5%
|
|
Euro Efficiency
|
96.9%
|
97.0%
|
|
MPPT Efficiency
|
＞99%
|
|
Equipment Protection
|
|
DC Polarity Reverse Connection Protection
|
yes
|
|
AC Output Overcurrent Protection
|
yes
|
|
AC Output Overvoltage Protection
|
yes
|
|
AC Output Short Circuit Protection
|
yes
|
|
Thermal Protection
|
yes
|
|
DC Terminal Insulation Impedance Monitoring
|
yes
|
|
DC Component Monitoring
|
yes
|
|
Ground Fault Current Monitoring
|
yes
|
|
Power Network Monitoring
|
yes
|
|
Island Protection Monitoring
|
yes
|
|
Earth Fault Detection
|
yes
|
|
DC Input Switch
|
yes
|
|
Overvoltage Load Drop Protection
|
yes
|
|
Residual Current (RCD) Detection
|
yes
|
|
Surge Protection Level
|
TYPE II(DC),TYPE II(AC)
|
|
Interface
|
|
Communication Interface
|
RS485/RS232 /WiFi/LAN
|
|
General Data
|
|
Operating Temperature Range (°C)
|
-25 to +65℃, >45℃ Derating
|
|
Permissible Ambient Humidity
|
0~100%
|
|
Permissible Altitude (m)
|
2000m
|
|
Noise (dB)
|
≤ 35 dB(A)
|
|
Ingress Protection(IP) Rating
|
IP 65
|
|
Inverter Topology
|
Non-Isolated
|
|
Over Voltage Category
|
OVC II(DC),OVC III(AC)
|
|
Cabinet Size (WxHxD mm)
|
280mm*310mm*184mm（Excluding connectors and brackets）
|
|
Weight [kg]
|
6.35
|
|
Warranty [year]
|
5 Years
|
|
Type Of Cooling
|
natural cooling
|
|
Grid Regulation
|
IEC 61727,IEC 62116,CEI 0-21,EN 50549，NRS 097,RD 140,UNE 217002,G98,G99,VDE-AR-N 4105
|
|
Safety EMC/Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
