Model
|
SUN-29.9K-SG01HP3-AU-BM3
|
SUN-35K-SG01HP3
-AU-BM3
|
SUN-40K-SG01HP3
-AU-BM4
|
SUN-50K-SG01HP3
-AU-BM4
|
|
Battery Input Data
|
|
|
Battery Type
|
Lithium-ion
|
|
Battery Voltage Range(V)
|
160-800
|
|
Max.Charging Current(A)
|
50+50
|
|
Max.Discharging Current(A)
|
50+50
|
|
Charging Strategy for Li-ion Battery
|
Self-adaption to BMS
|
|
Number of Battery Input
|
2
|
|
PV String Input Data
|
|
|
|
|
Max PV Input Power（W）
|
44850
|
52500
|
60000
|
75000
|
|
Max. PV Input Voltage (V)
|
1000
|
|
Start-up Voltage（V）
|
180
|
|
Min Input PV Operating Voltage Range (V)
|
180-1000
|
|
MPPT Range (V)
|
150-850
|
|
Full Load PV Voltage Range (V)
|
360-850
|
420-850
|
360-850
|
450-850
|
|
Rated PV Input Voltage (V)
|
600
|
|
Max. PV ISC(A)
|
55+55+55
|
55+55+55+55
|
|
PV Input Current (A)
|
36+36+36
|
36+36+36+36
|
|
No.of MPP Trackers
|
3
|
4
|
|
No.of Strings per MPP Tracker
|
2+2+2
|
2+2+2+2
|
|
AC Output Data
|
|
|
|
|
Rated AC Output Active Power（W）
|
29900
|
35000
|
40000
|
50000
|
|
Rated Apparent Output Power (VA)
|
29900
|
35000
|
40000
|
50000
|
|
Max. AC Output Power (W)
|
29900
|
35000
|
40000
|
50000
|
|
AC Output Rated Current (A)
|
43.4
|
50.8
|
58
|
72.5
|
|
Max AC Output Current（A）
|
43.4
|
50.8
|
58
|
72.5
|
|
Max. Three-phase Unbalanced Output Current (A)
|
60
|
60
|
70
|
83.3
|
|
Max Continuous AC Passthrough （A）
|
200
|
|
Peak Power (off grid)
|
1.5 times of rated power, 10s
|
Generator Input/Smart Load
/AC Couple Current (A)
|
43.4 / 200 / 43.4
|
50.8 / 200 / 50.8
|
58 / 200 / 58
|
72.5 / 200 / 72.5
|
|
Power Factor Adjustment Range
|
0.8 leading-0.8lagging
|
|
Output Frequency and Voltage
|
50/60Hz; 3L/N/PE 230/400, 240/415Vac
|
|
Grid Connection Form
|
3L+N+PE
|
|
Total Harmonics Current Distortion (THDi)
|
<3% (of nominal power)
|
|
DC current injection
|
<0.5%ln
|
|
Efficiency
|
|
|
Max Efficiency
|
97.60%
|
|
Euro Efficiency
|
97.00%
|
|
MPPT Efficiency
|
＞99.9%
|
|
Equipment Protection
|
|
|
Integrated
|
Anti-islanding Protection, PV String Input Reverse Polarity Protection,
Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection,
Output Shorted Protection, Surge Protection, Arc Fault Circuit Interruption (AFCI optional)
|
|
Protection Level
|
Class I
|
|
Over Voltage Category
|
DC Type II/AC Type III
|
|
Certifications and Standards
|
|
|
Grid Regulation
|
AS/NZS 4777.2
|
|
Safety EMC / Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
|
General Data
|
|
|
Operating Temperature Range (℃)
|
-40 to +60
℃, >45
℃ Derating
|
|
Cooling
|
Smart cooling
|
|
Noise (dB）
|
≤65 dB
|
|
Communication with BMS
|
RS485; CAN
|
|
Weight (kg)
|
80
|
|
Size (mm)
|
527W×894H×294D（Excluding connectors and brackets）
|
|
Protection Degree
|
IP65
|
|
Installation Style
|
Wall-mounted
|
|
Inverter topology
|
Non-isolated
|
|
Warranty
|
10 Years
|
