Model
|
SUN-3.6K-SG03LP1-EU
|
SUN-5K-SG03LP1-EU
|
SUN-6K-SG03LP1-EU
|
|
Battery Input Data
|
|
|
Battery Type
|
Lead-acid or Lithium-ion
|
|
Battery Voltage Range(V)
|
40-60
|
|
Max.Charging Current(A)
|
90
|
120
|
135
|
|
Max.Discharging Current(A)
|
90
|
120
|
135
|
|
Charging Strategy for Li-ion Battery
|
Self-adaption to BMS
|
|
Number of battery input
|
1
|
|
PV String Input Data
|
|
|
Max DC Input Power（W）
|
4680
|
6500
|
7800
|
|
Max DC Input Voltage（V）
|
500
|
|
Start-up Voltage（V）
|
125
|
|
MPPT Voltage Range（V）
|
150-425
|
|
Rated DC Input Voltage(V)
|
370
|
|
Max Input Short-Circuit Current（A）
|
17+17
|
|
Max Operating PV Input Current（A）
|
13+13
|
|
No.of MPP Trackers/No.of String Per MPP Tracker
|
2/1+1
|
|
AC Input/Output Data
|
|
|
Rated AC Input/Output Active Power（W）
|
3600
|
5000
|
6000
|
|
Max AC Input/Output Apparent Power （VA）
|
3960
|
5500
|
6600
|
|
Peak Power (off-grid)（W）
|
2 times of rated power,10s
|
|
Rated AC Input/Output Current（A）
|
16.4/15.7
|
22.7/21.7
|
27.3/26.1
|
|
Max AC Input/Output Current（A）
|
18/17.2
|
25/23.9
|
30/28.7
|
|
Max Continuous AC Passthrough (grid to load)（A）
|
35
|
40
|
|
Rated Input/Output Voltage/Range(V)
|
220V/230 0.85Un-1.1Un
|
|
Grid Connection Form
|
L+N+PE
|
|
Rated Input/Output Grid Frequency/Range
|
50Hz/45Hz-55Hz 60Hz/55Hz-65Hz
|
|
Power Factor Adjustment Range
|
0.8 leading-0.8lagging
|
|
Total Current Harmonic Distortion THDi
|
<3% (of nominal power)
|
|
DC Injection Current
|
<0.5%ln
|
|
Efficiency
|
|
|
Max Efficiency
|
97.6%
|
|
Euro Efficiency
|
96.5%
|
|
MPPT Efficiency
|
＞99%
|
|
Equipment Protection
|
|
|
DC Polarity Reverse Connection Protection
|
yes
|
|
AC Output Overcurrent Protection
|
yes
|
|
AC Output Overvoltage Protection
|
yes
|
|
AC Output Short Circuit Protection
|
yes
|
|
Thermal Protection
|
yes
|
|
DC Terminal Insulation Impedance Monitoring
|
yes
|
|
DC Component Monitoring
|
yes
|
|
Ground Fault Current Monitoring
|
yes
|
|
Power Network Monitoring
|
yes
|
|
Island Protection Monitoring
|
yes
|
|
Earth Fault Detection
|
yes
|
|
DC Input Switch
|
yes
|
|
Overvoltage Load Drop Protection
|
yes
|
|
Residual Current (RCD) Detection
|
yes
|
|
Surge Protection Level
|
TYPE II(DC),TYPE II(AC)
|
|
Interface
|
|
|
Communication Interface
|
WIFI,RS485,CAN
|
|
General Data
|
|
|
Operating Temperature Range
|
-40 to+60℃,＞45℃ Derating
|
|
Permissible Ambient Humidity
|
0~100%
|
|
Permissible Altitude
|
2000m
|
|
Noise
|
＜30 dB(A)
|
|
Ingress Protection(IP) Rating
|
IP 65
|
|
Inverter Topology
|
Non-Isolated
|
|
Over Voltage Category
|
OVC II(DC),OVC III(AC)
|
|
Cabinet size（W*H*D）[mm]
|
330×580×232 (Excluding Connectors and Brackets)
|
|
Weight[kg]
|
25
|
|
Warranty
|
5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
|
|
Type Of Cooling
|
Intelligent air cooling
|
|
Grid Regulation
|
IEC 61727,IEC 62116,CEI 0-21,EN 50549，NRS 097,RD 140,UNE 217002,OVE-Richtlinie R25,G99,VDE-AR-N 4105
|
|
Safety EMC/Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
